Taoglas TG.66.AN13W Apex 5G/4G Monopole Antenna
Taoglas TG.66.AN13W Apex 5G/4G Monopole Antenna
White Apex TG.66 miniature hinged monopole antenna covering 600-6000 MHz for full 5G/4G spectrum. Features a rotatable 90-degree hinged TS9 connector and compact 79 x 9.7 mm form factor. Designed for gateways, routers, IoT devices, public safety, POS, smart home, and robotics.
Overview
The TG.66.AN13W is a white miniature 5G/4G terminal mount monopole antenna from Taoglas's Apex series. Covering the full 600-6000 MHz 5G and 4G spectrum, it features a compact 79 x 9.7 mm form factor with a rotatable 90-degree hinged TS9 connector for flexible installation.
Key Features
Full 5G/4G coverage from 600-6000 MHz. Miniature form factor at just 79 x 9.7 mm. 90-degree hinged TS9 connector for flexible positioning. 6.12 dBi peak gain. Efficiencies above 45% across entire 5G/4G spectrum on small ground plane. Linear polarization. Operating temperature range of -40 to 85 degrees Celsius. RoHS compliant.
Applications
5G and 4G gateways and routers. IoT devices and edge computing. Public safety communications. Point of sale (POS) terminals. Smart home hubs and controllers. Robotics and autonomous systems.
Device Specifications:
- Frequency Range: 600-6000 MHz (full 5G/4G spectrum).
- Impedance: 50 Ohm.
- Peak Gain: 6.12 dBi.
- VSWR: 1.5:1.
- Polarization: Linear.
- Connector: TS9 with 90° hinged rotation.
- Efficiency: Above 45% across entire 5G/4G spectrum on small ground plane.
- Operating Temperature: -40°C to 85°C.
- Orientation: Hinged (90° rotatable).
- Compliance: RoHS compliant.
Weight and Dimensions:
- 11.3 grams.
- 9.7 mm wide.
- 9.7 mm deep.
- 79 mm height.
All functionality, features, specifications and other product information provided are subject to change without notice.
